Digital Projection M-Vision Laser 18K Series
Reference Guide
APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev D October 2019
3D formats
Standard
Resolution V-Freq (Hz) V-Total H-Freq (kHz) HDMI1/2 (*1) DisplayPort (*2) HB Dual- pipe HDMI (*3) HB DisplayPort (*3) Remarks Output Display Frame Rate
720p50 Frame Packing 1280x720 50.00 1470 37.50 √ *5 100
720p59 Frame Packing 1280x720 59.94 1470 44.96 √ *5 120
720p60 Frame Packing 1280x720 60.00 1470 45.00 √ *5 120
720p50 Top-and-Bottom 1280x720 50.00 750 37.50 √ √ *5 100
720p59 Top-and-Bottom 1280x720 59.94 750 44.96 √ √ *5 120
720p60 Top-and-Bottom 1280x720 60.00 750 45.00 √ √ *5 120
1080p23 Frame Packing 1920x1080 23.98 2205 26.97 √ *6 96
1080p24 Frame Packing 1920x1080 24.00 2205 27.00 √ *6 96
1080i50 Side-by-Side (Half) 1920x1080 50.00 1125 56.25 √ √ *5 100
1080i59 Side-by-Side (Half) 1920x1080 59.94 1125 67.43 √ √ *5 120
1080i60 Side-by-Side (Half) 1920x1080 60.00 1125 67.50 √ √ *5 120
1080p50 Side-by-Side (Half) 1920x1080 50.00 1125 56.25 √ √ *5 100
1080p59 Side-by-Side (Half) 1920x1080 59.94 1125 67.43 √ √ *5 120
1080p60 Side-by-Side (Half) 1920x1080 60.00 1125 67.50 √ √ *5 120
1080p50 Top-and-Bottom 1920x1080 50.00 1125 56.25 √ √ *5 100
1080p59 Top-and-Bottom 1920x1080 59.94 1125 67.43 √ √ *5 120
1080p60 Top-and-Bottom 1920x1080 60.00 1125 67.50 √ √ *5 100
1080p50 Frame Sequential 1920x1080 50.00 1125 56.25 √ √ *5 100
1080p59 Frame Sequential 1920x1080 59.94 1125 67.43 √ √ *5 120
1080p60 Frame Sequential 1920x1080 60.00 1125 67.50 √ √ *5 120
1080p100 Frame Sequential 1920x1080 100.00 1125 112.50 √ √ *4, *5 100
1080p120 Frame Sequential 1920x1080 120.00 1125 135.00 √ √ *4, *5 120
WUXGA_100_RB Frame Sequential 1920x1200 100.00 1258 125.72 √ √ *4, *5 100
WUXGA_120_RB Frame Sequential 1920x1200 120.00 1271 152.40 √ √ *4, *5 120
1080p23 Dual Pipe 1920x1080 23.98 1125 26.97 √ *6 96
1080p24 Dual Pipe 1920x1080 24.00 1125 27.00 √ *6 96
Notes
Remarks:
*1: Based on IT6802 chip
specifi cation
*2: Based on IT6535 chip
specifi cation
*3: Disable PIP funciton in this
situtation
*4: 8-bit / color
*5: Frame drop at scaler and frame
doubling at formatter
*6 Output display frame rate up to
96Hz for 24Hz 3D input
