APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev D October 2019
Signal Format Resolution H Freq. (KHz) Frame Rate (Hz) PCLK (MHz) DisplayPort
HDMI / HDBaseT
HD/SDI/3G
Remark
RGB YUV 8-bit YUV 10-bit YUV 12-bit
HDTV 1035i 60 XXXXX
1080i 50 X XXXXX
1080i 59.94 X XXXXX
1080i 60 X XXXXX
720p 50 X XXXXX
720p 59.94 X XXXXX
720p 60 X XXXXX
1080p 23.98 X XXXXX
1080p 24 X XXXXX
1080p 25 X XXXXX
1080p 29.97 X XXXXx
1080p 30 X XXXXX
1080p 50 X XXXXX
1080p 59.94 X XXXXX
1080p 60 X XXXXX
PsF formats 1080sf 27 24 74.250 X
1080sf 28.125 25 74.250 X
1080sf 33.75 30 74.250 X
HD-SDI 720p24 18 24 74.250 X
720p25 18.75 25 74.250 X
720p30 22.5 30 74.250 X
