page 48
Digital Projection M-Vision Laser 18K Series
Operating Guide
USING THE PROJECTOR
Rev D October 2019
Geometry menu
This menu allows you to compensate for image distortions caused by an unusual projection
angle or irregular screen surface.
Aspect Ratio
This feature defi nes the aspect ratio of the source. Use the
Setup > Screen Setting to defi ne the screen aspect ratio.
If you choose a preset aspect ratio from here, it will give you the best fi t for your selection.
Choose from:
• 5:4
• 4:3
• 16:10
• 16:9
• 1.88
• 2.35
• TheaterScope
• Source
• Unscaled
Notes
Only one of the following should be
used at any one time. Keystone,
4 Corners, Rotation,
Pincushion/Barrel and Arc
For more complex adjustments use
Custom Warp later in this section.
Image scaling and aspect ratio are
also infl uenced by Setup > Screen
Setting.
See next page for further information
about the TheaterScope aspect
ratio.
Geometry
Digital Zoom
Overscan
Aspect Ratio
Blanking
4 Corners
Rotation
Keystone
Pincushion / Barrel
Custom Warp
Off
Source
Off
Arc
To Next Page
