page 95
Digital Projection M-Vision Laser 18K Series
Reference Guide
APPENDIX C: WIRING DETAILS
Rev D October 2019
Appendix C: Wiring Details
RS232
9 way D-type connector
1 unused
2 Transmitted Data (TX)
3 Received Data (RX)
4 unused
5 Signal Ground
6 unused
7 unused
8 unused
9 unused
Notes
RS232:
pin view of female connector
