Digital Projection M-Vision Laser 18K Series
Operating Guide
USING THE PROJECTOR
Rev D October 2019
3D menu continued from previous page
3D types
In most situations you can use the
Auto setting to have the projector automatically detect the format. Otherwise, consider the notes below to
help you set up the 3D input manually.
The following 3D formats are supported:
• Dual Pipe (LEFT and RIGHT)
The left and right eye images are delivered on two separate HDMI links, which the projector will interleave for 3D display.
• Frame Sequential
Displayport and HDMI inputs can accept Frame Sequential formats where both left and right eye images are delivered on a single cable.
Up to 120Hz can be received and displayed. Frames rates of 50Hz or 60Hz will be displayed at 100Hz or 120Hz respectively.
.
For sequential 3D, an external sync is required to identify left and right frames. If no sync is available from the sequential source, the
projector will generate an output sync, but it may then be necessary to manually reset the dominance each time the player is started.
Notes
Processing through the projector
is limited 60Hz. Therefore while
120Hz sequential or Dual Pipe can
be accepted and displayed it will
drop to 60Hz for processing and
then frame double after processing.
L
R
Dual Pipe
HDMI 1
HDMI 2
LRLR
Frame Sequential
