Digital Projection M-Vision Laser 18K Series
Operating Guide
USING THE PROJECTOR
Rev D October 2019
3D menu continued from previous page
• Frame Packing
This format will be detected, re-synchronised, frame-multiplied and displayed at 96 Hz with the left eye /
right eye dominance automatically extracted from the video data. You need to optimize Dark Time and
Sync Delay manually to suit your chosen switching glasses.
• Top and Bottom
Sets the projector to reformat the video frames and map them to the display with the left eye / right
eye dominance automatically extracted from the video data. You need to optimize Dark Time and
Sync Delay manually to suit your chosen switching glasses.
• Side by Side (Half): interlaced and progressive, 50 and 60Hz
The side-by-side image will be de-interlaced (if appropriate), resized and then sequentially displayed at
100 or 120 Hz. The left eye / right eye dominance will be automatically extracted from the video data,
however you will need to optimize Dark Time and Sync Delay manually to suit your chosen switching
glasses.
Dark Time and Sync Delay need to be set only once, to optimize the image for the glasses in use.
L
R
Frame Packing
L
R
Top-and-Bottom
LR
Side-by-Side (Half)
Notes
