APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev D October 2019
Signal Format Resolution H Freq. (KHz) Frame Rate (Hz) PCLK (MHz) DisplayPort
HDMI / HDBaseT
HD/SDI/3G
Remark
RGB YUV 8-bit YUV 10-bit YUV 12-bit
PC
continued
1366 x 768 47.712 60 85.500 X X VESA DMT
1400X1050 65.317 60 121.750 X X VESA DMT
1400X1050 82.278 74.87 156.000 X X VESA DMT
1440 x 900 55.935 59.89 106.500 X X VESA DMT
1440 x 900 70.635 74.98 136.750 X X VESA DMT
1600x900 55.92 60 119.000 X X VESA GTF
1600x1200 75.000 60 162.000 X X VESA DMT
1680x1050 65.290 60 146.250 X X VESA DMT
1920x1080 53.225 47.95 135.403 X X VESA CVT
1920x1200 RB 61.816 50 158.250 X X VESA CVT
1920x1200 RB 74.038 60 154.000 X X VESA CVT
2048x1152 RB 72.000 60 162.000 X VESA CVT
2560x1600 RB 98.713 59.97 268.500 X VESA CVT
Apple Mac 640x480 66.59 X X Apple MAC
832x624 74.54 X X Apple MAC
1024x768 60.241 74.93 80.000 X X Apple MAC
1152x870 68.861 75.06 100.000 X X Apple MAC
SDTV 480i 59.94 X
1440x480i 60 XXXX
1440x576i 50 XXXX
576i 50 X
EDTV 480p 59.94 X XXXX
576p 50 X XXXX
