Digital Projection M-Vision Laser 18K Series
Reference Guide
POSITIONING THE IMAGE
Rev D October 2019
Any single adjustment outside the ranges specifi ed on the following page may result in an unacceptable level of distortion, particularly at the
corners of the image, due to the image passing through the periphery of the lens optics.
If the lens is to be shifted in two directions combined, the maximum range without distortion will be somewhat less, as can be seen in the
illustrations below.
Notes
Full horizontal or vertical shift Combined shift is reduced
