Dnepr MT10-36 - Electric Power Consumers; Ignition Coil

When installing the current - and-voltage regulator on a motor-
cycle care should be taken to r-eliably connect it with the "earth".
The curren't- and-voltage regulator "ea · rs" is its body provided with a
special terminal which is to be connected w-ith the motorcycle
"earth" by the screw wh ich fastens the current - and-voltage regula-
tor.
Electric Power Consumers
To .produce a t high - voltage · current, a distributor - and-contact brea -
ker TIM302-01 and ignition coil 5204 are provi rded. The position of
the i• gnition coil and of the contact breaker is shown in Fig. 33.
Fig. 33. Ignition coil and distributor-and - contact breaker
installed on the engine:
I- ignition coil 5204; 2- dis!ributor·and-contact breaker
DM302·01
Ignition Coil
The 5204 igniti·on coil (Fig. 34) has two taps for high-voltage
current. Each of the 'taps is intended to feed current to the appropri -
ate spark plugs of the cylinder
and is used in conjunctio n
with the contact breaker having
an ignition advance automatic
device.
The clearance between the
dischargers and the high-vol-
tage terminals is set equal to
Fig. 34. Two-lap ignit:on coil 13204 8-9 mm. During operation,
· check to see that the clearance
is within the specifi·ed limits (not to .be increased), also make sure
that the cu rrent-carrying wires are properly connected to the ter-
minals; keep the wir · es and terminals clean.
72
