CT100 inverter Detailed instructions of function parameters
139
time
3000.0s
20.0s
F13.02
Jogging running DEC
time
Setting range: 0.0 ～
3000.0s
Default value:
20.0s
F13.00: the set frequency for jogging running.
F13.01: the time it takes for the output frequency of the inverter increasing from
zero frequency to the maximum frequency F00.06.
F13.02: the time it takes for the output frequency of the inverter decreasing from
the maximum frequency F00.06 to zero frequency.
Note: The operating priority is as follows: forced deceleration > jogging running >
multi-step speed running > normal frequency running.
F13.03
ACC time 1
Setting range: 0.0 ～
3000.0s
Default value:
20.0s
F13.04
DEC time 1
Setting range: 0.0 ～
3000.0s
Default value:
20.0s
F13.05
ACC time 2
Setting range: 0.0 ～
3000.0s
Default value:
20.0s
F13.06
DEC time 2
Setting range: 0.0 ～
3000.0s
Default value:
20.0s
F13.07
ACC time 3
Setting range: 0.0 ～
3000.0s
Default value:
20.0s
F13.08
DEC time 3
Setting range: 0.0 ～
3000.0s
Default value:
20.0s
ACC time 1/2/3 is the same as ACC time 0 and DEC time 1/2/3 is same as DEC
time 0. You can select the corresponding ACC/DEC time by ACC/DEC time
selection 1 and 2.
F13.09
Emergency stop DEC
time (reserved)
Setting range: 0.0 ～
3000.0s
Default value:
1.0s
The DEC time is used when the inverter receives an “emergency stop
deceleration” signal from the input terminal, the time it takes for the output
frequency of the inverter decreasing from the maximum frequency F00.06 to
zero frequency. The inverter is decelerated to 0 and then it stops. This function is
