CT100 series inverters Keypad operation procedure
51
4.2.3 Motor parameter self-identification
To obtain good control performance, the motor must be self-identification of the
parameters to obtain the exact parameters of the controlled motor; you must
input correct motor parameters according to the name plate before identification,
CT series inverters will match the parameters with the standard motor
parameters.
The operation procedures for motor parameters identification are as follows:
First, select the keypad run command mode for the run command (F00.01).
Then enter the following parameters according to the actual motor parameters:
F01.02: Rated motor power;
F01.03: Rated motor frequency;
F01.04: Rated motor speed;
F01.05: Rated motor voltage;
F01.06: Rated motor current.
Note: The motor should be decoupled from the load. Otherwise, the identification
parameters may be incorrect. Set F01.12 to 1, if the motor is not decoupled from
the load, set F01.12 to 2 (see description of Function code F01.12 for detailed
motor identification) and then press the RUN key, the inverter will automatically
calculate the following parameters of the motor:
F01.07: Motor stator resistance;
F01.08: Motor rotor resistance;
F01.09: Motor stator and rotor inductance;
F01.10: Motor stator and rotor mutual inductance;
F01.11: Motor no-load current;
After the motor parameter identification is completed, the digital tube displays
END, otherwise the self-identification failed.
4.2.4 Password setting
CT series inverters provide user password protection function. When F05.03 is
set to non-zero, which is the user password. Exit the editing status of function
code and password protection will take effect in 60s. Press the ESC key again to
enter the editing status of function code and "8.8.8.8.8" will be displayed. You
need to input correct user password, or cannot enter.
To disable the password protection function, set F05.03 to 0.
