dolycon CT100 Series - Technical Parameters

CT100 series inverters Product overview
11
external braking resistors and you need to purchase the resistors by yourselves.
2. The inverters of power between CT100-4T-18G/22P-B～
CT100-4T-37G/45P-B are built-in with DC reactors. The inverters of power
between CT100-4T-45G/55P～CT100-4T-315G/355P are mounted with external
DC reactors and you need to purchase the reactors by yourselves. The inverters
of power between CT100-4T-355G～CT100-4T-500G are applied with input AC
reactors.
3. The above models are the standard general inverters, excluding the industrial
special inverters. You can customize non-standard inverters of other
specifications.
2.2.2 Technical parameters
Table 2-2 Technical parameters
Input and
output
parameters
Input voltage
Single-phase 220VAC±15%,
three-phase 380VAC±15%,.
three-phase 660VAC±15%,.
Input frequency
50～60Hz±5%
Output voltage
0～Rated input voltage
Output
frequency
0～600Hz
Technical
control
parameters
Control mode
V/F control, sensorless vector control, torque
control
Speed ratio
Open loop vector control 1: 100
Speed control
accuracy
±0.5%
Starting
frequency
0.00～10.00Hz
Overload
capacity
150% of rated current: 60s; 180% of rated
current: 10s; 200% of rated current: 1s
ACC and DEC
time
0.1～3000.0s
Energy braking
capacity
Operating voltage of braking unit: 320～750V
DC braking
capability
DC braking frequency: 0～300Hz;
DC braking waiting time: 0～50s;
DC braking current: 0.0～100.0%;
DC braking time: 0.0～50.0s;
Frequency
Analog setting, high-speed pulse setting,
