dolycon CT100 Series - Installation and Disassembly of the Keypad and the Cover Plate

CT100 series inverters Installation and wiring
22
Inverter model
Installation space size (mm)
A
B
CT100-4T-15G/18.5P～
CT100-4T-37G/45P
≧50
≧200
CT100-4T-45G/55P～
CT100-4T-315G/355P
≧50
≧300
3.3 Installation and disassembly of the keypad
and the cover plate
Figure 3-3 Keypad installation and disassembly of CT100-4T-11G/15P and below
power
