CT100 inverter Function parameters
55
5 Function parameters
CT100 series inverters have 16 groups of function codes F00～F14 and factory
group F15. The function codes have been divided into three levels. For example,
“F08.08” means the eighth function code in the P8 function group. F15 group is
factory group, and users are forbidden to access these parameters.
For the convenience of function codes setting, the function group number
corresponds to the first level menu, the function code corresponds to the second
level menu and the function code parameter corresponds to the third level menu.
1. Below are the instructions of the tables for function codes:
The first line “Function code”: codes of function parameter group and parameters
The second line “Name”: full name of function parameters
The third line “Detailed instruction of parameters”: Detailed illustration of the
function parameters
The forth line “Default value”: the original factory set value of the function
parameters
The fifth line “Modify”: the modifying character of function codes (the parameters
can be modified or not and the modifying conditions), below are the instructions:
“○”: means the set value of the parameter can be modified in stop and running
state；
“☆”: means the set value of the parameter cannot be modified in running state；
“●”: means the value of the parameter is the real detection value which cannot
be modified.
(The inverter has limited the automatic inspection of the modifying character of
the parameters to help users avoid modifying by mistake)
The sixth line “No.”: the serial number of the function parameters
2. “Parameter radix” is decimal (DEC), if the parameter is expressed by hex, then
the parameter is separated from each other when editing. The setting range of
certain bits are hex (0～F).
3. “Default value” means the function parameter will restore to the default value
during default parameters restoring. But the detected parameter or recorded
value will not be restored.
4. For a better parameter protection, the inverter provides password protection to
the parameters and only factory and administrator can modify the function codes.
After setting the user password (F05.03 is non-zero) and press the ESC key to
enter into the parameter editing state, the system goes into user password
