CT100 series inverters Installation and wiring
27
3.4.3 Specifications of the cables, the circuit breakers
and the contactors
Table 3-3 Specifications of the cables, the circuit breakers and the contactors
Inverter model
Cables of
main
circuit (m2)
Circuit
breakers
(A)
Rated current
of contactors
(A)
Braking
units/Braking
resistors
CT100-2S-0.7G-B
2.5
16
10
300W
150Ω
CT100-2S-1.5G-B
4
20
16
CT100-2S-2.2G-B
4
32
25
CT100-4T-0.7G-B
2.5
10
10
CT100-4T-1.5G-B
2.5
16
10
CT100-4T-2.2G-B
2.5
16
10
CT100-4T-4.0G/5.5P-B
4
25
16
450W
100Ω
CT100-4T-5.5G/7.5P-B
4
32
25
600W
75Ω
CT100-4T-7.5G/11P-B
4
40
32
CT100-4T-11G/15P-B
4
63
40
1200W
38Ω
CT100-4T-15G/18.5P-B
6
63
40
1800W
25Ω
CT100-4T-18.5G/22P-B
6
100
65
CT100-4T-22G/30P-B
10
100
65
CT100-4T-30G/37P-B
16
125
80
5000W
10Ω
CT100-4T-37G/45P-B
16
160
80
CT100-4T-45G/55P
25
200
95
The braking
resistors are
optional
according to
braking units
CT100-4T-55G/75P
35
200
125
CT100-4T-75G/90P
50
250
160
CT100-4T-90G/110P
70
250
160
CT100-4T-110G/132P
95
350
350
