dolycon CT100 Series - Page 162

CT100 inverter Communication protocol
158
0005H: -E.Lv- status
The address of
the
communication
setting value
2000H
Communication set frequency
(-10000～10000, 10000
corresponds to 100.00%, -10000
corresponds to -100.00%)
W/R
2001H
Torque set value (-1000～1000,
1000 corresponds to 100.0%)
2002H
Upper limit frequency setting (0～
Fmax, unit: 0.01Hz)
W/R
2003H
PID reference (0～1000, 1000
corresponds to 100.0%)
W/R
2004H
PID feedback (0～1000, 1000
corresponds to 100.0%)
W/R
The address of
the
running/stoppin
g parameter
3000H
Running frequency (0～Fmax,
unit 0.01Hz)
R
3001H
Set frequency (0～Fmax, unit
0.01Hz)
R
3002H
Output current (0.0～3000.0, unit
0.1A)
R
3003H
Output voltage (0～1200V, unit
1V)
R
3004H
Running speed (0～65535, unit
1RPM)
R
3005H
Bus voltage (0～2000.0, unit
0.1V)
R
3006H
Output power (-300.0～300.0%,
unit 0.1%, 100% corresponds to
motor rated power)
R
3007H
Output torque (-250.0～250.0%,
unit 0.1%, 100% corresponds to
motor rated torque)
R
