CT100 inverter Detailed instructions of function parameters
89
2: analog input AI2
3: HDI pulse input
4: Process PID output
5: multi-step speed
6: 485 communication
The Y frequency source has the same meaning as the X frequency source.
F00.04
Reference object of Y
frequency source
Setting range: 0～1
Default value: 0
0: relative to the max. frequency
1: relative to frequency source X
Y frequency needs to combine F00.03 and F00.04 for calculation.
When the Y frequency reference is the maximum output frequency (F00.06), it is
calculated in the same way as the X frequency.
When the reference frequency is X frequency, then calculate the X frequency at
first. Then take X frequency as a reference to calculate the Y frequency. For
example, when the Y frequency is set by the analog input AI1 and the analog
input AI1 corresponds to 50.0%, the X frequency is 100.00Hz and finally the Y
frequency is 50.0% * 100.00Hz = 50.00Hz. X frequency calculation refers to
F00.02.
F00.05
Frequency combination
reference operation
Setting range: 0～
3
Default value: 0
0: X
1: Y
2: X+Y
3: Max (X, Y)
The combination of the set frequency mode can combine the terminal frequency
sources to switch the set frequency channels flexibly, such as switching between
X frequency source and Y frequency source, switching between X frequency
source and X+Y frequency source. The set frequency is invalid for torque control
and is only valid for speed control.
F00.06
Max. frequency
Setting range: F00.08～
600.00Hz
Default value:
50.00Hz
The ACC/DEC time is calculated with the maximum frequency as a reference.
F00.07
Upper limit
Setting range: F00.09 ～
Default value:
