CT100 inverter Detailed instructions of function parameters
93
asynchronous motor
3000.0kW
Depend on
model
F01.03
Rated frequency of
asynchronous motor
Setting range: 10.00Hz ～
F00.06
Default value:
50.00Hz
F01.04
Rated speed of
asynchronous motor
Setting range: 1 ～
36000rpm
Default value:
Depend on
model
F01.05
Rated voltage of
asynchronous motor
Setting range: 0～500V
Default value:
Depend on
model
F01.06
Rated current of
asynchronous motor
Setting range: 0.8 ～
3000.0A
Default value:
Depend on
model
Set these parameters correctly according to the motor name plate.
F01.07
Stator resistance of
asynchronous motor
Setting range: 0.001 ～
65.535Ω
Default value:
Depend on
model
F01.08
Rotor resistance of
asynchronous motor
Setting range: 0.001 ～
65.535Ω
Default value:
Depend on
model
F01.09
Inductance of
asynchronous motor
Setting range: 0.1 ～
6553.5mH
Default value:
Depend on
model
F01.10
Mutual inductance
of asynchronous
motor
Setting range: 0.1 ～
6553.5mH
Default value:
Depend on
model
F01.11
Non-load current of
asynchronous motor
Setting range: 0.1 ～
6553.5A
Default value:
Depend on
model
These parameters can be obtained by motor parameter autotuning. The
correctness of these parameters has a direct effect on the control performance of
the motor.
F01.12
Motor parameters
autotuning
Setting range: 0～2
Default value: 0
0: no actuation
1: dynamic autotuning
In order to ensure the dynamic control performance of the inverter, select the
