dormakaba ED900 Installation Instructions – Double egress door Chapter 15
. Full width cover option – Vac pair power cable connections
Fig. 15.9.2 ED900 115 Vac pair power cable – inactive door
1 ED900 115 Vac plug
from 115 Vac socket,
female connection
2 ED900 power
supply circuit board
socket, male
connection
3 ED900 power
supply 115 Vac plug,
male connection
4 ED900 power
printed circuit board
socket, female
connection.
5 115 Vac pair power
cable plug, male
connection
.. Inactive door
. Insert Vac interconnecting cable plug
() into ED power supply circuit board
socket () (Fig...).
3
Fig. 15.9.1 Inactive door cables
3 115 Vac interconnect
cable plug, male
connection
Fig. 15.9.4 ED900 115Vac pair power cable
– active door
6
7
6 ED900 power cord,
male connection
7 115 Vac pair power
cable plug, female
connection
7
Fig. 15.9.3 Active door cables
7 115 Vac pair power
cable plug, female
connection
1
2
3
4
5
4
5
4
.. Active door.
. Insert Vac interconnecting cable plug
() into ED power cord socket ()
(Fig...).
