dormakaba ED900 Installation Instructions – Double egress door Chapter 22
71
. Parameters
Step 
Press right button greater than  s to
enter program mode.
Step 
Press up or down button to scroll through
parameters until desired parameter is
displayed.
Step 
Press right button to display current
parameter value.
Step 
Press right button again to enable
editing of value, display will start
flashing.
Step 
Press up or down button to select
desired parameter value.
Step 
Press right button to save selected
value. Display stops flashing.
Step 
Press left button to return to selected
parameter.
Step 
Press up or down button to scroll
through parameters until next desired
parameter is displayed.
Step 
Press left button for a minimum of  s
to exit program mode.
Fig. 22.1.1 dormakaba handheld terminal
.. Configuration parameters.
Configuration parameters (Para. ..) are set during
first commissioning (Chapter ).
• Reference Para. .. for configuration parameter
detail.
.. Driving parameters.
Driving parameters can be set once first commissioning
has been completed.
• Reference Para. .. for a list of driving parameters.
• Reference Appendix A for driving parameter detail.
1 Program switch,es,
close position
.. Changing parameter values.
. Set program switches to the CLOSE position
. Use  button keypad as outlined in Steps  through 
to view or change parameter values.
Fig. 22.1.2 Program switches
Fig. 22.1.3 4 button keypad,
2 digit display
2 2 digit display
5 4 button keypad
 Parameters
.. Firmware version and updates.
• Operator firmware version is displayed during first
commissioning. Reference Chapter .
• dormakaba handheld can be used to check operator
firmware version and to perform firmware updates.
Reference Appendix C, dormakaba handheld, or
dormakaba handheld manual.
> 3s Reset
< 3s Quit
> 3s
PRG
< 3s
LEARN
Fact-Setup
> 3s
> 8s
2
5
