Instructions for use Isolette 8000 plus SW 5.n 131
Reprocessing
12.1.3 Removing the heater radiator and impeller
1 On devices without the humidification system option, remove the heater/impeller
cover (A).
2 On devices with the optional humidification system, pull the water reservoir
partially out, and remove the heater/impeller cover (B) and the duct cover (C).
WARNING
Risk of death or serious injury
The heater can be sufficiently hot to cause burns.
► Avoid removing or touching the heater until the device has been switched off for
at least 45 minutes.
3 When the device has cooled, remove the heater radiator (D).
4 Pull the impeller (E) off the motor shaft.
104
A
B
C
D
E
