Dräger Isolette 8000 plus - Sensor Module

Instructions for use Isolette 8000 plus SW 5.n 31
Overview
4.5 Sensor Module
4.5.1 Top view
4.5.2 Bottom view
018
A Peripheral skin probe connector
B Central skin probe connector
C Alarm indicator
D Scale connector
A
B
C
D
019
E Controller interface cable
F Air, temperature, and humidity sensor housing
G Oxygen sensor housing
E
F
G
