Instructions for use Isolette 8000 plus SW 5.n 37
Overview
4.10 Technical definitions
Weight limit warning (DIN
compatible rails)
Do Not Discard
EC Rep Date of manufacture
Symbol Meaning
Latch lock/unlock and rail loading warn-
ing (Fairfield compatible rails)
Warning: Use only with software version
5.00 or higher.
Total mass including safe working load
Symbol Meaning Symbol Meaning
Term Definition
Accuracy of incubator
temperature indication
The displayed average incubator temperature versus the
actual average temperature in the patient compartment.
Average incubator
temperature
The average of the incubator temperature readings,
taken at regular intervals, achieved during temperature
equilibrium.
Incubator temperature Temperature of the air at a point 10 cm (4 inches) above
the center of the mattress surface in the compartment.
Incubator temperature
equilibrium
The condition reached when the incubator temperature
does not vary more than 1 °C over a period of one hour
(also known as steady temperature condition).
Incubator warm-up
time
The time required for the incubator temperature to rise
11 °C (20 °F), when the air set point is at least 12 °C
(22 °F) above the ambient temperature.
Set point The temperature selected by the user at the temperature
control (also known as control temperature).
Temperature over-
shoot
The amount by which the incubator temperature exceeds
the average incubator temperature at incubator tempera-
ture equilibrium as a result of an increase in set point.
Temperature unifor-
mity
The amount by which the average temperatures at the
center of the mattress quadrants, 10 cm (4 in) above the
mattress surface, differ from the average incubator tem-
perature at incubator temperature equilibrium.
