Instructions for use Isolette 8000 plus SW 5.n 53
Assembly and preparation
CAUTION
Risk of injury or damage to the device
Using an incomplete water reservoir can prevent the system from operating
correctly.
► Ensure that the reservoir lid is installed.
► Ensure that the cover on the filling inlet is closed.
4 Insert the water reservoir assembly (C) in the shell with the latch open. Then
slide it in fully and lock it in place by pushing in the latch.
6.5.1 Installing the collection bottle for the condensation management
system
1 Slide the new collection bottle (A) onto the bracket located underneath the left
side of the incubator.
2 Remove the caps from the ports on the collection bottle.
The large port on top of the collection bottle must remain uncapped during
operation to ensure that water drains properly into the bottle.
3 Connect the condensation management hose that protrudes from the underside
of the incubator to the patient port (B) on the side of the collection bottle.
4 Secure the hose clamp (C).
