Viewing The Instrument Pages
72
5.4.9 CAN ERROR MESSAGES
When connected to a suitable CAN engine the controller displays alarm status messages from the
ECU.
Alarm
ECU Warning
Warning
Press to access the list of current active Engine DTCs (Diagnostic Trouble Codes).
Engine DTCs
The code interpreted by the module shows on the display as a text message.
Additionally, the manufacturer’s code is shown.
Water Level
Low
Xxx,xxx,xxx
NOTE: - For details on these code meanings, refer to the ECU instructions provided by
the engine manufacturer, or contact the engine manufacturer for further assistance.
NOTE: - For further details on connection to electronic engines please refer to Electronic
engines and DSE wiring. Part No. 057-004
Type of alarm that is triggered in the
DSE module (i.e. Warning or
Shutdown)
