Front  fuse box (A) key
Pos El. item Rat.
1 EMS/ABS/IMU 5 A
2 DASH/BBS/SMEC 7.5 A
3 Front optical unit 5 A
4 SBS -
5 Accessories 5 A
6 Injection relay 20 A
7 Diagnostics/
Recharge
7.5 A
8 Spare 20 A
9 Spare 15 A
10 Spare 5 A
Front right fuse box (B) key
Pos El. item Rat.
1 EMS powered relays 25 A
2 Fuel pump relay 10 A
3  relay -
Front right fuse box (B) key
4 Instrument panel 15 A
5 Black Box System
(BBS)
15 A
6 ABS 1 25 A
7 ABS 2 10 A
8 Spare 25 A
9 Spare 15 A
10 Spare 10 A
