The main fuse (C) is located on the right side of the
fuse box (B Fig 217), on solenoid (D).
To reach it, it is necessary to remove the tank cover as
described in chapter “Charging the and the
protection cap (E). A blown fuse can be identified by
breakage of the inner filament (F).
Switch the ignition key to OFF before replacing
the fuse to avoid possible
Never use a fuse with a rating other than
specified. Failure to observe this rule may damage
the electric system or even cause fire.
Fig 218
Fig 219
290
