1-28
Chapter 1 Before Operation
3/7 page
No. Item Details
[1] Middle jog If a sheet feeder or a collator is connected to the DBM-600 as a
upstream unit, each time the number of the specied sheets reaches
the stitching section, one jogging motion is made. Specify the
number of sheets.
Setting range: 0, 2 to 9, default: 0
When set to “0,” a jogging motion is not made.
You can set this item when a sheet feeder or a collator is connected
to the DBM-600. If a collator is connected, you need to use the
intelligent function.
[2] The number of jogs(*1) Specify the number of jogs at the stitching section.
+: The number of jogs increases.
-: The number of jogs decreases.
Setting range: 1 to 9, default: 1
[3] The number of sheets to be
processed(*2)
Specify the number of sheets for manual feed or merged collation
when a upstream unit is connected to the DBM-600.
Setting range: fold on 2 to 30, fold o 2 to 50
Default: 2
[4] Page number Displays the current page number.
[5] Previous page key Returns to the previous page.
[6] Next page key Goes to the next page.
(*1) The processing speed is slower with more jogs.
(*2) This item is deactivated when the PC CONTROLLER is connected to the system.
To Next Page
