Service Instructions 755 A/756 A - 00.0 - 02/2019 227

27.2.3 Changing the knives

Fig. 223: Changing the knives (1)

To change the knife:

1. Remove the fabric sliding plate.

2. Swivel up the machine head.

3. Loosen screws (1) and (2).

4. Remove the tape feeder.

WARNING

Risk of injury from sharp parts!

Cutting injuries may be sustained.

Do not reach into the knife blade when changing

the knife.

(1) - Screws (2) - Screws
