Additional equipment

Service Instructions 755 A/756 A - 00.0 - 02/2019 235

27.4 Assembling the pocket bag clamp

Fig. 231: Assembling the pocket bag clamp

To assemble the pocket bag clamp:

1. Tighten the pocket bag clamp (1) on the fabric sliding plate using

screws (2).

The pocket bag clamp (1) is held in place by a magnet on the left-hand

side of the fabric sliding plate.

2. Set the height of the magnet using the screw thread.

(1) - Pocket bag clamp (2) - Screws

②

①
