8.1.9 Changing Parameters at the Special Level (C) in the DA40MS02 Controls.
ATTENTION!
This level contains control parameters whose values must
only be changed in exceptional circumstances. A change in
these parameters may only occur after consultation with
DÜRKOPP ADLER.
Avtivating the special level (programming level C).
Prerequisite:
The parameter 798 at the mechanic level (B) is set to I (<798> = I). See
Chapter 8.1.8
–
Turn the mains switch off and, after approx. 2 sec., on again. The special level C is
activated.
The setting of the parameters and the parameter values occurs in the same manner as
at the mechanic level. See Chapter 8.1.8
The special level C is exited again by turning off the mains switch.
Note
The special level C contains all parameters (including those at levels A and B).
8.1.10 Checking and Setting the Positions at the DA40MS02 Controls
Checking and setting the reference position
–
Activate the mechanic level (B). See Chapter 8.1.8
–
Call up parameter 700.
–
Tap the pedal forward briefly, the machine starts and positions in the reference
position which corresponds to position "
F
" of the handwheel.
–
Is the handwheel in position "
F
"?
- If not, then the handwheel must be turned to position "F".
- Tap the pedal forward. The machine makes one revolution and
positions in the corrected position.
- The position can be corrected repeatedly.
–
If no further correction is required, exit the mechanic level or call up the next
parameter, the reference position is saved.
