29 / 84 SM-SG-2 Ev3/25062014
- undo self securing nuts M6 and remove both springs from the rear bracket
- undo both bolts M10x45 and pull cylinder out from the fork rod and from the bracket
- remove spring bracket by driving out a key
Mounting:
- Install the spring bracket and secure it by the key
- Screw up a new cylinder to the bracket M10x45
