4 Replacement Procedures 4.1 Overview
4-12 [CONFIDENTIAL] PORTÉGÉ X30W-J, dynabook V*/VZ*/VC* Series Maintenance Manual (960-941)
Grip Color
Some screws have a colored grip area.
[Nylok screw]
Grip color : Blue (The seven screws fixing the HINGE ASSY are Yellow)
Screw Notation
To make maintenance of the computer easier, markings of the kinds of the screws including
the types and lengths of the screws are indicated on the computer body.
Format:
Screw type + Screw length (mm)
Screw shape
B: Bind screw
F: Flat head screw
S: Super thin head screw
T: Tapping screw
U: Other screws (Unique screws: pan head, stud, etc.)
Example:
B6
... 6mm BIND screw
Screw color/material
B: Black/Nickel
C: Silver/Non-Hexavalent Chromate
U: Other screws (Unique screws: such as stud, etc.)
Grip area
