dynabook PORTEGE X30W-J - SIM Card

4.2 SIM Card 4 Replacement Procedures
PORTÉGÉ X30W-J, dynabook V*/VZ*/VC* Series Maintenance Manual (960-941) [CONFIDENTIAL] 4-13
4.2 SIM Card
Removing the SIM Card
To remove the SIM Card, follow the steps below and refer to Figure 4-1.
CAUTION: Before you remove the SIM card, refer to the card’s documentation and to
your operating system documentation for proper procedures and
precautions.
1. Insert a slender object (about 0.8mm) such as a straightened paper clip into the eject hole
and pull the SIM card tray.
2. Remove the SIM card from the SIM card tray.
Figure 4-1 Removing the SIM card
Installing the SIM Card
To install the SIM Card, follow the steps below and refer to Figure 4-1.
1. Set the SIM card on the SIM card tray.
2. Set the SIM card tray (with the SIM card) into the SIM card slot.
Rev.01
