4.4 BASE ASSY
Removing the BASE ASSY
To remove the BASE ASSY or BASE LTE ASSY, follow the steps below and refer to Figure
4-3 and 4-4.
1. Click “Start” – “Power” and then click “Shut down” while holding down the SHIFT
key to turn off the power of the computer.
2. Disconnect the AC adapter and other external devices from the computer.
3. Turn over the computer.
4. Remove the following screws securing the BASE ASSY or BASE LTE ASSY.
< non 5G/LTE model >
M2.54B FLAT HEAD screw 4 (Described as “4” in the Figure 4-3)
M2.56B FLAT HEAD screw 8 (Described as “6” in the Figure 4-3)
< 5G/LTE (JP) model >
M2.54B TORX HEAD screw 2 (Described as “4” in the Figure 4-4)
M2.56B FLAT HEAD screw 8 (Described as “6” in the Figure 4-4)
< 5G/LTE (US, UK) model >
M2.54B FLAT HEAD screw 2 (Described as “4” in the Figure 4-4)
M2.56B FLAT HEAD screw 8 (Described as “6” in the Figure 4-4)
NOTE: When the color of the computer is dark blue, fix the BASE ASSY or BASE LTE
ASSY with the dark blue electrodeposition coating screws.
When the color of the computer is black, fix the BASE ASSY or BASE LTE ASSY
with the black nickel screws.
5. Remove the BASE ASSY or BASE LTE ASSY while releasing the latches.
