3 Tests and Diagnostics
3-16
[CONFIDENTIAL] PORTÉGÉ X30W-J, dynabook V*/VZ*/VC* Series Maintenance Manual (960-941)
3.8 Keyboard Test
To execute the Keyboard Test, select 3 from the DIAGNOSTIC TEST Menu (Main Test
Menu), press Enter and follow the directions on the screen. (Move the highlight bar to the
subtest you want to execute and press Enter.
Subtest 1 [Key-Code Test]
This test displays the key code and scan code of a pressed key. To back to the
Keyboard test menu screen, press Del + Enter.
(Displayed information)
( Presses Key Code : xx )
( Presses Scan Code : xx )
Subtest 2 [Touch Pad Test]
This test gets the information of moving amount of the touch pad, both for direction
X and Y, and pressing (ON)/releasing (OFF) information of the button A (left click
button) and B (right click button), and displays the information in real time. To back
to the Keyboard test menu screen, press the button A and B.
(Displayed information)
[X: xxxx] [Y: xxxx] [Button A : x] [Button B : x]
