dynabook PORTEGE X30W-J Maintenance Manual

1 Hardware Overview
1-20 [CONFIDENTIAL] PORTÉGÉ X30W-J, dynabook V*/VZ*/VC* Series Maintenance Manual (960-941)
1.8 AC Adapter
The AC adapter is also used to charge the battery. At the charging, connect it to
Thunderbolt/USB Type-C connector on the PC or to the USB Type-C adapter. It corresponds
to USB-PD.
The following table lists the AC adapter specifications.
Table 1-9 AC adapter specifications
Item Specifications
Maker Chicony
Parts code G71C000LR210 (2-pin) G71C000LS210 (3-pin)
Power 65W
Input voltage 100V/240V
Input frequency 50Hz to 60Hz
Output voltage 20V
Output current 3.25A
Dimension (mm)
63(W) x 63(L) x 28(H) (Typ.)
Cable length (mm)
1800(±50)
