dynabook PORTEGE X30W-J Maintenance Manual

1 Hardware Overview
PORTÉGÉ X30W-J, dynabook V*/VZ*/VC* Series Maintenance Manual (960-941) [CONFIDENTIAL] 1-15
1.4 TFT Color Display
The TFT color display consists of 13.3-inch LCD module and capacitive touch panel by
direct-bonding.
The LCD module used for the TFT color display uses a backlight as the light source and can
display a maximum of 16.77 million colors with 1,920x1,080 (FHD) resolutions.
Following shows a view of the LCD module and lists the specifications.
Figure 1-5 LCD module
Table 1-3 LCD module specifications
Item Specifications
Maker WACOM
Part code G83C000L3110
Outline [mm] (Typ) 298.76±0.3(W) × 177.84(Max)(H) × 2.05Max(D)
Number of Dot
1920(H) ×1080(V)
(1 pixel = R+G+B dot)
Active display area [mm]
293.76(H) × 165.24(V)
Dot pitch [mm]
0.153(H)×0.153(V)
Pixel configuration R.G.B. Vertical Stripe
Weight [g] 170 (max)
