Table 9 – Submenus of the Advanced Menu
J1939 Setup
Manufacturer
John Deere, Volvo, Cummins,
Yanmar, Detroit Diesel, Others
Loss of ECM Enable, Disable
Display Group 1 Enable, Disable
Display Group 2 Enable, Disable
DTC Display Disable, Enable
Active DTC Log Disable, Enable
Read Stored DTC Disable, Enable
Auto Power ECM Disable, Enable
ECM Power Delay 5-30 seconds
Cummins Idle Disable, GCP Enable, GC1 Enable
High Engine Tmp
Input Pin Disable, Analog 2-7
Signal Source J1939, Switch input, Sender 1, 2, or 3
Bypass Delay 10-60 Seconds
Switch Setting GND = Fail, Open = Fail
Shorted Sender Disable, Warning, Shutdown
Open Sender Disable, Warning, Shutdown
Units Fahrenheit, Celsius
Warning Level 10-265°F, 10-265°C
Failure Level 10-265°F, 10-265°C
Oil Pressure
Input Pin Reserve, Analog 2-7
Signal Source J1939, Switch input, Sender 1, 2 or 3
Bypass Delay 10-60 Seconds
Switch Setting GND = Fail, Open = Fail
Shorted Sender Disable, Warning, Shutdown
Open Sender Disable, Warning, Shutdown
Units PSI, KPa
Warning Level 0-90 PSI, 0-90 KPa
Failure Level 0-90 PSI, 0-90 KPa
Fuel Level
Input Pin Reserve, Analog 2-7
Signal Source Switch input, Sender
Bypass Delay 10-60 Seconds
Switch Setting GND = Warning, OPEN = Warning,
GND = Fail, Open = Fail
Shorted Sender Disable, Warning, Shutdown
Open Sender Disable, Warning, Shutdown
Units Percentage
Warning Level 0-90%
Failure Level 0-90%
0% Fuel Level
0-1000 Ohms (data sheet or measured
value)
25% Fuel Level
0-1000 Ohms (data sheet or measured
value)
50% Fuel Level
0-1000 Ohms (data sheet or measured
value)
75% Fuel Level
0-1000 Ohms (data sheet or measured
value)
100% Fuel Level
0-1000 Ohms (data sheet or measured
value)
