DynaGen GSC400 Series User Manual

47 of 105
Oil Level
Input Pin Reserve, Analog 2-7
Signal Source J1939, Switch input, Sender
Bypass Delay 10-60 Seconds
Switch Setting GND = Fail, Open = Fail
Shorted Sender Disable, Warning, Shutdown
Open Sender Disable, Warning, Shutdown
Units Percentage
Warning Level 0-100%
Failure Level 0-100%
Fuel In Basin
Input Pin Reserve, Analog 2-7
Signal Source J1939, Switch input, Sender
Bypass Delay 10-60 Seconds
Switch Setting GND = Fail, Open = Fail
Shorted Sender Disable, Warning, Shutdown
Open Sender Disable, Warning, Shutdown
Units Percentage
Warning Level 0-90%
Failure Level 0-90%
Low Engine Tmp
Input Pin Reserve, Analog 2-7
Signal Source J1939, Switch input, Sender
Bypass Delay 10-60 Seconds
Switch Setting GND = Fail, Open = Fail
Shorted Sender Disable, Warning, Shutdown
Open Sender Disable, Warning, Shutdown
Units Fahrenheit, Celsius
Warning Level 10-265°F, 10-265°C
Speed Sensing
Signal Source J1939, Mag pickup, Gen output
Rated Freq 10-9990 Hz
Rated RPM 200-4000 RPM
Over RPM Warn 100-5000 RPM
Over RPM Fail 100-5000 RPM
Under RPM Warn 100-5000 RPM
Under RPM Fail 100-5000 RPM
AC Frequency
DisconnectFreq 1-100 Hz
Over Freq Warn 1-100 Hz
Over Freq Fail 1-100 Hz
UnderFreq Warn 1-100 Hz
UnderFreq Fail 1-100 Hz
A/C Voltage
Voltage Source Disable, Enable
Voltage Display Line-Line, Line-Neutral, Both
Voltage Group
1-Single, 2-Three, 3-Hi Wye, 4-Three
phase
Group 1 Setting 3 Wire Single, 2 Wire Single
Group 4 Setting Four Wire Delta, Three Phase
Over Volt Warn 1 0-700 VAC
Over Volt Fail 1 0-700 VAC
Under Volt Warn 1 0-700 VAC
Under Volt Fail 1 0-700 VAC
Over Volt Warn 2 0-700 VAC
