DynaGen GSC400 Series User Manual

48 of 105
Over Volt Fail 2 0-700 VAC
Under Volt Warn 2 0-700 VAC
Under Volt Fail 2 0-700 VAC
Over Volt Warn 3 0-700 VAC
Over Volt Fail 3 0-700 VAC
Under Volt Warn 3 0-700 VAC
Under Volt Fail 3 0-700 VAC
Over Volt Warn 4 0-700 VAC
Over Volt Fail 4 0-700 VAC
Under Volt Warn 4 0-700 VAC
Under Volt Fail 4 0-700 VAC
A/C Current
Current source Disable, Enable
Turns Ratio 5-5000A:5A
Over Current Warn 1 0-6500 A
Over Current Fail 1 0-6500 A
Over Current Warn 2 0-6500 A
Over Current Fail 2 0-6500 A
Over Current Warn 3 0-6500 A
Over Current Fail 3 0-6500 A
Over Current Warn 4 0-6500 A
Over Current Fail 4 0-6500 A
Hi Wye Current 100%, 50%
Cur Warn Latch Disable, Enable
Engine Logic
Delay to Start 0-60 seconds
Glowplug Time 0-60 seconds
Crank Time 3-60 seconds
MidHeat Time 0-60 seconds
Crank Rest Time 1-60 seconds
Crank Attempts 1-60
Fuel Crank Rest
Disable, Enable
False Restart
Disable, Enable
Post-Heat Time 0-60 seconds
ETS On Duration 0-30 seconds
Warm-up Time
0-600 seconds
RPM Disconnect
100-2000 RPM
Cool Down Delay
0-600 seconds
Crank Oil pres
0-90 Psi
Digital Output Setup
All selections apply to
each individual output
Extra Relay Disable, Warm-Up, ETS,
Output A Glowplug, Cooldown,
Output B Over Crank , High Temp Fail ,
Output C High Temp warn, Low Oil Fail ,
Output D Low Oil Warning, Under RPM Fail,
Output E Under RPM Warn, Over RPM Fail
Output F
Over RPM Warn, Low Fuel Fail
Output G
Low Fuel Warn, Battery Fail,
Output H
Battery Warn, Low Coolant Fail,
Low Coolant warn, Not in Auto,
Failure, Crank Rest,
Engine Running, Crank On,
Exerciser Alarm, Recharge Alarm
