GBK60348: Issue 3 27
2.6.2 Force Sleep Mode – 4Q
In addition to the automatic sleep timeout that can be set with the Sleep Mode
Enable parameter (see DSM 5.3.9.8), the Force Sleep Mode can put the AJR to sleep
immediately.
Sleep Mode starts at the Sleep Home Level (see 2.6).
Deflect the joystick forward to enter Sleep Mode (go to sleep)
The DX System switches off.
To wake up (switch on) the DX System:
Press any button on the keypad.
If Enable Joystick Wakeup (DSM 5.3.9.10) has the value 'yes', deflect the joystick in
any direction.
The AJR starts up in the Drive Home Level (see 2.6.1).
2.6.3 Horn Mode – 4Q
Horn Mode starts at the
Horn Home Level (see 2.6).
Deflect the joystick forward to sound the horn.
Any button, or
Any joystick deflection*
*Depending on the value of the Enable
Joystick Wakeup parameter, see DSM 5.3.9.10
