Dynamic DX2-REM550 - Installation and Testing; Specifications

GBK60348: Issue 3 41
3 Installation and testing
3.1 Specifications
3.1.1 Electrical Specifications
Parameter
Value
Operating voltage range
18V – 32V DC (nom. 24V)
Charger rating
max 12A RMS continuous,
limited by DXBUS rating
Quiescent current
< 0.25mA Off, typically 200mA On
3.1.2 Mechanical Specifications
Parameter
Value
Material
Polycarbonate / PET injection-moulded
plastic
Protection rating
IPx4
Shipping weight
650 g (excluding packing material)
Operating forces
Less than 800 g
Min
Nominal
Max
Units
Tube mount diameter
15 (5/8)
19 (3/4)
22 (7/8)
mm (in)
Operating temperature range
-25 (-13)
50 (122)
°C (°F)
Storage temperature range
-40 (-40)
70 (158)
°C (°F)
Operating humidity range
0
95
%RH
Warning:
Do not operate the DX2 AJR if the cover is not installed correctly.
The cover is an essential part of the water entry protection.
