34 GBK60348: Issue 3
2.6.8 ECU2 Mode – 4Q
ECU2 Mode gives access to channel 7 and 8 of an ECU Module that has been setup
as ECU1, and to all 8 channels of an ECU Module that has been setup as ECU2.
The 8 channels of ECU2 are numbered 9-16.
This mode is only available if one of the ECU Menu parameters (see 4.2.1.9) is set to
'Yes' and an ECU Module is detected in the system.
Only the enabled channels will be shown.
ECU2 Mode starts at the ECU2 Home Level (see 2.6).
Deflect the joystick forward to enter the ECU2 Channel Selection Mode
ECU2 Channel Selection Mode
starts up with the ECU channel
that was last selected.
Deflect the joystick right
to select the desired channel.
Deflect the joystick forward
to toggle the selected channel (not latched).
Deflect the joystick reverse to toggle the selected channel (latched).
Deflect the joystick left to return to the ECU2 Home Level.
Note:
The orientation of the joystick depends on the value of the
Accessory Menu Navigation (4.2.1.6) parameter.
The description of the 4Q ECU2 menu assumes that this
parameter has the value 'Normal'.
*Channel Selection Mode will show the last selected channel
