Eagle TT-4 - Exhaust and Intake System Components

107
REV30 8.4.15 TT4-8 4TNV98
EXHAUST SYSTEM
EXHAUST & INTAKE SYSTEM
Item Part Number Qty. Description
1 A-TT4-00258-2 1 MUFFLER
2 TT08-57-001-KA 1 2 PIECE EXHAUST PIPE ASSEMBLY
3 129930-13200 1 EXHAUST GASKET
4 A-TT4-00260 2 EXHAUST HANGAR
5 A-TT4-00254 3 2 IN HEAVY DUTY EXHAUST CLAMP
6 TT08-57-002-SA 2 SPACER, 3/8 ID X 2 LG
7 NPN 2 HCS, 3/8-16 UNC X 3.0, GR 8
8 NPN 4 FLAT WASHER, 3/8
9 NPN 2 HEX NUT, 3/8-16 UNC
10 NPN 1 HCS, 5/16-18 UNC X 1.0, GR 8
11 NPN 2 FLAT WASHER, 5/16
12 NPN 1 HEX NUT, 5/16-18 UNC
13 A-TT4-00255 1 EXHAUST BRACKET YANMAR TT4-8
13
Note: Item 13 used on tractors
manufactured before June 2013.
