Eagle TT-4 - Quick Start Guide (H30 Display;Controller)

119
REV30 8.4.15 TT4-8 4TNV98
INSTRUMENT PANEL - H30 DISPLAY/CONTROLLER - NO LONGER AVAILABLE
Item Part Number Qty Description
1 A-TT8-00415 1 ELECTRONIC CONTROLLER DISPLAY
2 C-TT4-00411-1 1 DASH PANEL (NO INSTRUMENTS)
3 A-TT4-00433-1 1 SPOTLIGHT TOGGLE SWITCH(OPTIONAL)
4 A-TT4-00423-2 1 HEADLIGHT SWITCH
5 A-TT4-00609 1 HEATER FAN SWITCH(OPTIONAL)
6 A-TT4-00608 1 HEATER CONTROL CABLE(OPTIONAL)
7 A-TT4-00428 1 HORN BUTTON
8 AE-OPT-0084 1 AMMETER GUAGE (OPTIONAL)
9 AE-OPT-0152 1 TRANS TEMP GAUGE (OPTIONAL)
10 AE-OPT-0066 1 E-STOP (OPTIONAL)
OPERATOR COMPARTMENT
