Eagle TT-4 - Battery Disconnect and Fuses

139
REV30 8.4.15 TT4-8 4TNV98
LIGHTS & ELECTRICAL
HEADLIGHT, TAIL LIGHT, SPOT LIGHT ASSEMBLY
Item Part Number Qty Description
1 A-TT4-00291-6
2
HEADLIGHT W/ (OPTIONAL)TURN SIGNAL
2 A-TT4-00291-5
1
REAR FACING SPOT LIGHT (OPTION)
3 A-TT4-00292 2 TAILLIGHT
Item Part Number Qty Description
4 73-1912 2 TAIL LENS COVER
5 1157
2
REPLACEMENT BRAKE LIGHT BULB
6 1156 2 REPLACEMENT REVERSE LIGHT BULB
TAILLIGHT ASSEMBLY
Item Part Number Qty Description
7 H6545
2
REPLACEMENT HEADLIGHT SEALED BEAM
8 1157 2 REPLACEMENT TURN SIGNAL BULB
9 H3
1
REPLACEMENT BULB, SPOTLIGHT
HEADLIGHT & SPOTLIGHT
OPTIONS NOT SHOWN
Item Part Number Qty Description
10 AE-OPT-0076 2 ROOF MOUNTED TURN SIGNAL LAMP
11 AE-OPT-0099A 1
MASTER BATTERY DISCONNECT
SWITCHPLOCKOUT LEVER KIT (OPTION)
BATTERY DISCONNECT & FUSES
Item Part Number Qty Description
11 AE-OPT-0099 1 MASTER BATTERY DISCONNECT SWITCH
12 NPN 4 25 AMP ACG GLASS ROUND FUSE
13 A-TT4-00299 1 FUSE BLOCK (W/O FUSES)
14 A-TT4-00300 1 TERMINAL BLOCK
