Eagle TT-4 - Dana Axle Torque Specifications

65
REV30 8.4.15 TT4-8 4TNV98
POSITION THREAD
WRENCH TORQUE
(LBS.-FT)
Drive Pinion Nut 3/4 - 16 175-225
Differential Bearing Cup Cap Screws 1/2 - 13 70-90
Ring Gear Cap Screws 3/8 - 24 45-65
Cover Screws 5/16 - 18 28-33 (Note A)
Axle Shaft Bearing & Brake Retainer Nuts 3/8 - 24 40-50
Spindle Mounting Nuts 3/8 - 24 40
Spindle Mounting Nuts 7/16 - 20 50-60
Tie Rod Stud Nut 1/2 - 20 35 Min (Note B)
Tie Rod Stud Nut 9/16 - 18 35 Min (Note B)
Tie Rod Clamp Nuts 3/8 - 24 15-25
Tie Rod Clamp Nuts 7/16 - 20 25-40
Steering Arm Nuts 9/16 / 18 80-100
Steering Bolt Stop Screw & Jam Nut 3/8 - 24 10-20
RECOMMENDED TORQUE SPECIFICATIONS FOR DANA 44 AXLE (FRONT)
POSITION THREAD
WRENCH TORQUE
(LBS.-FT)
Drive Pinion Nut 7/8 - 14 240-300
Differential Bearing Cup Cap Screws 1/2 - 13 70-90
Ring Gear Cap Screws 1/2 - 20 100-120
Ring Gear Cap Screws 1/2 - 20 120-14 (Note A)
Cover Screws 3/8 - 16 30-40
Brake Retainer Nuts 7/16 - 20 64-70
Axle Shaft Flange Nuts 7/16 - 20 64-70
Upper Kingpin 1 1/8 - 12 500-600
Kingpin Cap Cap Screws 1/2 - 20 70-90
Spindle Mounting Nuts 1/2 - 20 60-80
Tie Rod Stud Nut 5/8 - 18 70 Min (Note B)
Tie Rod Clamp Nuts 1/2 - 20 35-45
Steering Arm Nuts 1/2 - 20 70-90
Steering Bolt Stop Screw & Jam Nut 1/2 - 20 10-20
A. For Grade 9 fastener with locking serrations on underside of cap screw head or nut.
B. If cotter pin cannot be installed after minimum torque is attained, the nut must be advanced until cotter pin
can be installed.
RECOMMENDED TORQUE SPECIFICATIONS FOR DANA 60 AXLE (REAR)
AXLES
