Eagle TT-4 - Intake Manifold (Yanmar Diesel)

109
REV30 8.4.15 TT4-8 4TNV98
INTAKE MANIFOLD—YANMAR TIER II DIESEL
Item Part Number Qty Description
1 119129-77520 1 INTAKE ELBOW
2 119129-77020 1 GASKET, AIR HEATER
3 119005-77050 1 AIR HEATER
4 121850-77021 1 GASKET, AIR HEATER
5 26106-080352 4 BOLT, M8 X 35 PLATED
6 26106-080802 2 BOLT, M8 X 80 PLATED
7 26106-080452 8 BOLT, M8 X 45 PLATED
8 129944-12110 1 INTAKE MANIFOLD
9 129907-12110 1 GASKET, INTAKE MANIFOLD
4
1
2
3
5
6
7
8
9
EXHAUST & INTAKE SYSTEM
