Eagle TT-4 - Alternator Yanmar Tier II & III Engine with Cab or Transit Pro Option

23
REV30 8.4.15 TT4-8 4TNV98
1
2
3
4
5
6
7
Item Part Number Qty Description
1 AE-OPT-0021 1 105A ALTERNATOR
2 NPN 1 1.40 SPACER
3 NPN 1 .23 SPACER
4 NPN 1 M10-1.5 x 130
5 NPN 2 5/16 FLAT WASHER
6 119940-77270 1 SPACER
7 26306-100002 1 M10-1.5 LOCK NUT
8 9440 1 ALTERNATOR BELT(NOT SHOWN)
POWER TRAIN
105 AMP HIGH OUTPUT ALTERNATOR ASSEMBLY
(INSTALLED ON SOME UNITS PRIOR TO APRIL, 2015)
